For sound engineers
Technical spec
& stage plot
Our input list, stage plot, monitor mixes and power, for the three-piece and four-piece line-ups. We bring our own DI boxes, pedals and IEMs — you supply mics, stands, XLR leads and power.
- Mics
- SM58 (or equivalent) on a stand
- Monitoring
- Wired IEMs preferred — we bring our own; otherwise a wedge
- DI & FX
- We bring our own DI boxes and pedals — we only need XLR leads
Trio
Three-piece — 9 channels, 3 mixes
9 XLR channels · 3 monitor mixes · 8 power outlets across the stage.
Stage plot · audience view
Liam
Banjo · Vocals · Stomp
MIX 1
Mark
Guitar · Vocals
MIX 2
Thomas
Whistle · Mandolin · Stomp
MIX 3
| Ch | Performer | Input | Needs from venue | FX | Monitoring | Power |
|---|---|---|---|---|---|---|
| 1 | ThomasWhistle · Mandolin · Stomp | Whistle mic (SM58) | 1 mic, 1 XLR lead, 1 mic stand | Plate reverb | Wired IEM preferably, otherwise wedge | Minimum 3 power outlets |
| 2 | Mandolin — XLR out | Own DI box; XLR lead only | Own pedals | |||
| 3 | Stomp box (sub drop) — XLR out | Own DI box; XLR lead only | None | |||
| 4 | MarkGuitar · Vocals | Vocal mic (SM58) | 1 mic, 1 XLR lead, 1 mic stand | Plate reverb | Wired IEM preferably, otherwise wedge | Minimum 3 power outlets |
| 5 | Guitar — XLR out | Own DI box; XLR lead only | Own pedals | |||
| 6 | Octave pedal (bass) — XLR out | Own DI box; XLR lead only | Own pedals | |||
| 7 | LiamBanjo · Vocals · Stomp | Vocal mic (SM58) | 1 mic, 1 XLR lead, 1 mic stand | Plate reverb | Wired IEM preferably, otherwise wedge | Minimum 2 power outlets |
| 8 | Banjo — XLR out | Own DI box; XLR lead only | Own pedals | |||
| 9 | Stomp box (kick drum) — XLR out | Own DI box; XLR lead only | None | |||
| Total | 9 XLR channels | 3 mixes | 8 outlets | |||
Trio + guest fiddle
Four-piece — 11 channels, 4 mixes
11 XLR channels · 4 monitor mixes · 9 power outlets across the stage.
Stage plot · audience view
Guest fiddle
Fiddle · Vocals
MIX 1
Liam
Banjo · Vocals · Stomp
MIX 2
Mark
Guitar · Vocals
MIX 3
Thomas
Whistle · Mandolin · Stomp
MIX 4
| Ch | Performer | Input | Needs from venue | FX | Monitoring | Power |
|---|---|---|---|---|---|---|
| 1 | ThomasWhistle · Mandolin · Stomp | Whistle mic (SM58) | 1 mic, 1 XLR lead, 1 mic stand | Plate reverb | Wired IEM preferably, otherwise wedge | Minimum 3 power outlets |
| 2 | Mandolin — XLR out | Own DI box; XLR lead only | Own pedals | |||
| 3 | Stomp box (sub drop) — XLR out | Own DI box; XLR lead only | None | |||
| 4 | MarkGuitar · Vocals | Vocal mic (SM58) | 1 mic, 1 XLR lead, 1 mic stand | Plate reverb | Wired IEM preferably, otherwise wedge | Minimum 3 power outlets |
| 5 | Guitar — XLR out | Own DI box; XLR lead only | Own pedals | |||
| 6 | Octave pedal (bass) — XLR out | Own DI box; XLR lead only | Own pedals | |||
| 7 | LiamBanjo · Vocals · Stomp | Vocal mic (SM58) | 1 mic, 1 XLR lead, 1 mic stand | Plate reverb | Wired IEM preferably, otherwise wedge | Minimum 2 power outlets |
| 8 | Banjo — XLR out | Own DI box; XLR lead only | Own pedals | |||
| 9 | Stomp box (kick drum) — XLR out | Own DI box; XLR lead only | None | |||
| 10 | Guest fiddleFiddle · Vocals | Vocal mic (SM58) | 1 mic, 1 XLR lead, 1 mic stand | Plate reverb | Wired IEM preferably, otherwise wedge | Minimum 1 power outlet |
| 11 | Fiddle — XLR out | Own DI box; XLR lead only | Own pedals | |||
| Total | 11 XLR channels | 4 mixes | 9 outlets | |||
Notes
Sound, monitors and FX
- 1
Separate monitor mixes for each performer if possible (3 mixes). We carry wired IEMs which can be used instead of, or alongside, wedge monitors. For the four-piece, 4 mixes.
- 2
Each monitor mix should carry a good balance of all instruments and vocals (stomp and bass may be left out of the monitors if needed).
- 3
Our sound relies heavily on low-frequency effects, so subs are required where possible — a driving kick and bass-heavy sound is preferable. “Sub drop” is a sine sweep from roughly 72 Hz down to 20 Hz.
- 4
Reverb (plate or similar) on the vocal and whistle mics. Solo whistle pieces want heavy reverb. If possible, relay the FX subtly back into the monitor mix.
- 5
On Allen & Heath QU or Behringer/Midas XR consoles we can provide a scene for reference ahead of the show.
Consoles: Allen & Heath QU series · Behringer / Midas XR series — we can send a scene file in advance.
Downloads
PDF versions
- Three-piece technical spec & stage plot9 channels · 3 mixes · 8 outletsPDF
- Four-piece technical spec & stage plot11 channels · 4 mixes · 9 outletsPDF
